Vehicle Specification
Overall Vehicle Size (L x W x H)
2450x1220x1530mm  (96.5x48x60.2 inch)
Ground Clearance (mm)
152mm (5.9inch)
Wheelbase (mm)
1860mm (73.2inch)
Weight with full equipment’s
283kg (623.9lbs)
Front/Rear Brakes
Front Dual Hydraulic Disk
Rear Single Axle Hydraulic Disk
Parking Brake
Hand-Actuated
Front Tires
AT21x7-10
Rear Tires
AT22x10-10
Front Suspension
Dual A-Arm
Rear Suspension
Dual Shock Swing arm
Cargo Box Dimensions (L x W x H)
554×1220×165mm  (21.8×48×6.5inch)
Box Capacity (kg)
30kg (66.1lbs)
Fuel Capacity (L)
9.5L (2.5gal)
Engine specification
Cooling
Air cooled
Engine Capacity (cc)
168.9cc
Volumetric Compression Ratio
9.2:1
Drive System Type
2WD
Engine Type
Single Cylinder 4-Stroke
Fuel System
Electronic Fuel Injection
Ignition type
E.C.U
Start type
Electric
Horsepower
11HP
Transmission/Final Drive
CVT F/N/R; Chain Drive
Maximum  power (Kw /r/min)
8.3KW/8000RPM
Maximum Torque (Nm /r/min)
11N·m/6000RPM
Top Speed (km/h)
51km/h (32mile)
